Colour | Green/Yellow |
---|---|
Shrink Ratio | 2:1 Minimum |
Shrink Temperature | +90°C to start shrinking |
Temperature Rating | -55°C to +135°C continuous operating temperature |
Dispenser Box - Dimensions | H 180 x W 50 x D 167 mm |
Resistances | Resistant to common fluids and solvents. Tested against fungus with no growth occurring. |
---|---|
Approved to: UL 224 VW-1; MIL-I-23053/5 | Class 1 & 3 |
Dielectric Strength | Minimum 19.7kV/mm. Tested to ASTM D-2671 |
Volume Resistivity | Min 10¹³Ohm-cm. Tested to ASTM D-876 |
Heatshrink - Starting Ø (A) | 12.7mm |
---|---|
Heatshrink - Recovered Ø (B) | 6.4mm |
Heatshrink - Recovered Wall Thickness (C) | 0.56mm |
Heatshrink - Led Flat Width | 22mm |
